ZWY Medium Crawler Mucking Loader for Large Underground Tunnel
- Type / Model
- ZWY
View Details
Unit Description
Muck loader is also called excavating loader, integrates multiple functions including excavation, conveying, loading, running. Because mucking loader has strong ability to adapt the space, high working efficiency, less pollution to the air inside of the tunnel, Siton underground mucking loader becomes a very important mechanical equipment applied in railways tunnels, highway tunnels, water diversion tunnels, coal mine coal lanes, semi-coal lanes, and national defense.
Specifications
- Product
- Crawler Muck Loaders
- Place of Origin
- Jiangxi, China
- Certificate
- FOPS/ROPS
- Application
- Mine, water diversion, railways tunnel, Highway tunnel
Technical Parameters
| Item | Unit | ZWY-60/30L | ZWY-80/37L | ZWY-80/45L |
| Overall Dimension (L*W*H) | mm | 6750X1600X1775 | 6950X1682X1775 | 8500X1762X2210 |
| Coverage Area (W*H) | m | 2.2X2.2 | 2.4X2.4 | 2.6X2.8 |
| Total Weight | KG | 7800 | 8300 | 11900 |
| Main Motors | KW | 30 | 37 | 45 |
| Loading Capacity | m³/h | 60 | 80 | 80 |
| System Pressure | Mpa | 25 | 25 | 25 |
| Digging Width | mm | 3100 | 4100 | 5300 |
| Excavating Heigh | mm | 2300 | 2400 | 2540 |
| Digging Distance | mm | 1480 | 1800 | 1970 |
| Excavating Depth | mm | 500 | 520 | 540 |
| Width of Crawler Plate | mm | 350 | 350 | 300 |
| Width of Crawler Inner | mm | 885 | 977 | 1100 |
| Climbing ability | ° | ≤30 | ≤30 | ≤15 |
| Tramming Speed | km/h | 1.1 | 1.1 | max1.4 |
| Ground Clearance | mm | 280 | 280 | 330 |
| Width of Transport Trough | mm | 488 | 580 | 620 |
| Speed of Chain Supporting Plate | m/min | 20 | 20 | max30 |
| Form of Transport Trough Mechanism | / | Single chain single motor | ||
| Unloading Distance (Variable) | mm | 1600 | 1600 | 1700 |
| Unload Height (Variable) | mm | 1350 | 1350 | 1670 |
| Item | Unit | ZWY-100/45L | ZWY-120/55L | ZWY-150/55L |
| Overall Dimension (L*W*H) | mm | 8100X1910X2100 | 7550X1900X2300 | 9500X2360X2450 |
| Coverage Area(W*H) | m | 2.5X2.5 | 3.0X3.0 | 3.2X3.2 |
| Total Weight | KG | 1200 | 12800 | 15300 |
| Main Motors | KW | 45 | 55 | 55 |
| Loading Capacity | m³/h | 100 | 120 | 150 |
| System Pressure | Mpa | 28 | 28 | 32 |
| Digging Width | mm | 5300 | 5900 | 6870 |
| Excavating Heigh | mm | 2540 | 3330 | 3563 |
| Digging Distance | mm | 1970 | 2470 | 2950 |
| Excavating Depth | mm | 540 | 800 | 915 |
| Width of Crawler Plate | mm | 350 | 450 | 500 |
| Width of Crawler Inner | mm | 941 | 945 | 1360 |
| Climbing ability | ° | ≤30 | ≤15 | ≤30 |
| Tramming Speed | km/h | max1.4 | max1.8 | max1.8 |
| Ground Clearance | mm | 310 | 330 | 350 |
| Width of Transport Trough | mm | 580 | 620 | 782 |
| Speed of Chain Supporting Plate | m/min | max30 | max28 | max28 |
| Form of Transport Trough Mechanism | / | Single chain single motor | Single chain single motor or Double chain double motor | |
| Unloading Distance (Variable) | mm | 1700 | 1700 | 3170 |
| Unload Height (Variable) | mm | 1670 | 1700 | 1770 |
Parameter tables use the technical terms from the manufacturer data sheet.
